Mounting, wiring, connecting, system interfaces, configuration guidelines
12.3 System interfaces
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
247
12.3.5 Closing the system interfaces with the system interface cover
Examples of closing the system interface with the system interface cover
Figure 12-39 Examples of closing the system interface with the system interface cover
System interface on the operator panels (degree of protection IP54):
To ensure degree of protection IP 54
• press the cover into the socket as far as it will go when it is used for the first time!
• When fastening the operator panel with the screws supplied, do not apply an excessive
tightening torque.
