Mounting, wiring, connecting, system interfaces, configuration guidelines
12.1 Mounting
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
189
12.1.3 Mounting of digital modules DM-F Local and DM-F PROFIsafe
See Manual SIMOCODE pro fail-safe digital modules
(https://support.automation.siemens.com/WW/view/en/50564852
),
Chapter "Mounting and connection."
12.1.4 Mounting of current measuring modules
You can attach these system components as follows:
● Current measuring modules up to 100 A: Standard mounting rail mounting or screw
attachment with mounting lugs (Order No: 3RV2928-0B) and screws for mounting on a
level surface. These mounting lugs are suitable only for current measuring modules and
current / voltage measuring modules! For current measuring modules up to 25 A you will
require an additional 25 mm spacer.
● Current measuring modules up to 200 A: Rail-mounting or screw attachment
● Current measuring modules up to 630 A: Screw mounting.
