11.3 Diagram of diagnostics data
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
181
11.3 Diagram of diagnostics data
The following table shows the diagnostics data in the 3UF50 compatibility mode:
Table 11- 3 Diagram of the diagnostics data in the 3UF50 compatibility mode
Byte.
Bit
Setup 3UF50 -
Device-specific diagnostics
according to DP standard
SIMOCODE DP
Byte.
Bit
Setup 3UF50 -
Device-specific diagnostics
according to DPV1 SIMOCODE DP
Equivalent in SIMOCODE pro V
6
0x0B
Same as 3UF-50 diagnostics
7 0x81
8
0x04
6
0x0E
9
0x00
7.0
Free
10.0
Free
7.1 Event: DP block 10.1 Event: DP block Event - Startup parameter block
active
7.2 Event: Emergency start 10.2 Event: Emergency start Status - Emergency start
executed
7.3 Event: HW test OK 10.3 Event: HW test OK
• No fault - HW fault basic unit
• No fault - Module fault
• No fault - temporary
components
7.4
Free
10.4
Free
—
7.5
Event: Ext. event 1
10.5
Event: Ext. event 1
Event - Ext. fault 5
7.6
Event: Ext. event 2
10.6
Event: Ext. event 2
Event - Ext. fault 6
7.7
Event: Ext. event 3
10.7
Event: Ext. event 3
—
8.0
Warning: Ext. warning
11.0
Warning: Ext. warning
Warning: Ext. fault 3
8.1
Warning: Unbalance > 40 %
11.1
Warning: Unbalance > 40 %
Warning - Unbalance
8.2
Event: Failure PLC-CPU
11.2
Event: Failure PLC-CPU
Status - PLC / PCS (intervened)
8.3 Warning: Sensor short circuit 11.3 Warning: Sensor short circuit Warning - Thermistor short
circuit
8.4 Event: Cooling down period active 11.4 Event: Cooling down period active Status - Cooling down period
active
8.5
Status: TPF
11.5
Status: TPF
Status - Test position (TPF)
8.6
Free
11.6
Free
—
8.7
Free
11.7
Free
—
9.0 Warning: Ground fault 12.0 Warning: Ground fault
• Warning internal ground fault
or
• Warning external ground
fault
9.1
Warning: Overload
12.1
Warning: Overload
Warning - Overload
9.2
Warning: Overload + unbalance
12.2
Warning: Overload + unbalance
Warning - Overload + unbalance
9.3 Warning: I1 response level
overshot
12.3 Warning: I1 response level overshot Warning - Warning level I >
