Siemens SIMOCODE pro V MR

3UF50 compatibility mode
11.3 Diagram of diagnostics data
SIMOCODE pro
182 System Manual, 05/2019, A5E40507475002A/RS-AD/004
Byte.
Bit
Setup 3UF50 -
Device-specific diagnostics
according to DP standard
SIMOCODE DP
Byte.
Bit
Setup 3UF50 -
Device-specific diagnostics
according to DPV1 SIMOCODE DP
Equivalent in SIMOCODE pro V
9.4 Warning: I1 response level
undershot
12.4 Warning: I1 response level
undershot
Warning - Warning level I <
9.5 Warning: I2 response level
overshot
12.5 Warning: I2 response level overshot —
9.6 Warning: I2 response level
undershot
12.6 Warning: I2 response level
undershot
—
9.7 Warning: Thermistor 12.7 Warning: Thermistor
• Warning - Thermistor
overload
• Warning - Thermistor open
circuit
• Warning - TM warning T >
• Warning - TM sensor fault
• Warning - TM out of range
10.0 Trip: Ground fault 13.0 Trip: Ground fault
• Fault - internal ground fault
or
• Fault - ext. ground fault
10.1
Trip: Overload
13.1
Trip: Overload
Fault - overload
10.2
Trip: Overload + unbalance
13.2
Trip: Overload + unbalance
Fault - overload + phase failure
10.3
Trip: I1 response level overshot
13.3
Trip: I1 response level overshot
Fault - trip level I >
10.4
Trip: I1 response level undershot
13.4
Trip: I1 response level undershot
Fault - trip level I <
10.5
Trip: I2 response level overshot
13.5
Trip: I2 response level overshot
—
10.6
Trip: I2 response level undershot
13.6
Trip: I2 response level undershot
—
10.7 Trip: Thermistor 13.7 Trip: Thermistor
• Fault - thermistor overload
• Fault - thermistor short
circuit
• Fault - thermistor open
circuit
• Fault - TM trip T >
• Fault - TM sensor fault
• Fault - TM out of range
11.0
Trip: FB ON
14.0
Trip: FB ON
Fault - feedback (FB) ON
11.1
Trip: FB OFF
14.1
Trip: FB OFF
Fault - feedback (FB) OFF
11.2
Trip: Stalled rotor
14.2
Trip: Stalled rotor
Fault - stalled rotor
11.3
Trip: Stalled positioner
14.3
Trip: Stalled positioner
Fault - stalled positioner
11.4
Trip: Double 0
14.4
Trip: Double 0
Fault - double 0
11.5
Trip: Double 1
14.5
Trip: Double 1
Fault - double 1
11.6
Trip: End position
14.6
Trip: End position
Fault - end position
11.7
Trip: Antivalence
14.7
Trip: Antivalence
Fault - antivalence
12.0 Trip: ESB 15.0 Trip: ESB Fault - ext. fault 4
