Siemens SIMOCODE pro V MR

3UF50 compatibility mode
11.3 Diagram of diagnostics data
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
183
Byte.
Bit
Setup 3UF50 -
Device-specific diagnostics
according to DP standard
SIMOCODE DP
Byte.
Bit
Setup 3UF50 -
Device-specific diagnostics
according to DPV1 SIMOCODE DP
Equivalent in SIMOCODE pro V
12.1 Trip: OPO 15.1 Trip: OPO Fault - Operational Protection
Off (OPO)
12.2
Trip: UVO
15.2
Trip: UVO
Fault - power failure (UVO)
12.3
Trip: Ext. fault 1
15.3
Trip: Ext. fault 1
Fault - ext. fault 1
12.4 Trip: Ext. fault 2 15.4 Trip: Ext. fault 2 Fault - ext. fault 2
12.5 Trip: TPF fault 15.5 Trip: TPF fault Fault - Test Position Feedback
(TPF)
12.6
Trip: Runtime ON
15.6
Trip: Runtime ON
Fault - execution ON command
12.7 Trip: Runtime OFF 15.7 Trip: Runtime OFF Fault - execution STOP
command
13.0
Trip: Parameter fault 0
16.0
Trip: Parameter fault 0
Fault - parameterization
13.1
Trip: Parameter fault 1
16.1
Trip: Parameter fault 1
—
13.2
Trip: Parameter fault 2
16.2
Trip: Parameter fault 2
—
13.3
Trip: Parameter fault 3
16.3
Trip: Parameter fault 3
—
13.4
Trip: Parameter fault 4
16.4
Trip: Parameter fault 4
Fault - configuration error
13.5
Trip: Parameter fault 5
16.5
Trip: Parameter fault 5
13.6
Trip: Parameter fault 6
16.6
Trip: Parameter fault 6
13.7
Trip: Parameter fault 7
16.7
Trip: Parameter fault 7
Fault - hardware fault basic unit
14 -
15
Number of overload trips Number of overload trips
16 -
17
I of the overload trip [% / IE)] Last trip current
18 -
19
Operating hours [10 h] Motor operating hours
