Technical data
15.8 Technical data of the operator panels
SIMOCODE pro
360 System Manual, 05/2019, A5E40507475002A/RS-AD/004
15.8 Technical data of the operator panels
15.8.1 Technical data of the operator panel
Technical data of the operator panel
Installation in a cabinet door or in a front panel, with IP54 system interface
• Red / green / yellow "DEVICE" LED • Red blocked: "Function test negative, device disabled"
• Green: "Ready for operation"
• Flashing green: "No connection to basic unit"
• Yellow: "Memory module or addressing plug detected"
• OFF: "No control supply voltage"
• Green "BUS" LED • Continuous light: "Communication with PLC/PCS"
• Flashing: "Baud rate recognized/communication with PC/PG"
• Red "GEN. FAULT" LED • Continuous light /
• Flashing: "Feeder fault," e.g. overload tripping
• 3 yellow LEDs / 4 green LEDs
For freely assigning any status signals
• Test / Reset • Resets the device after tripping
• Function test (system self-test)
• Operation of memory module or addressing plug
• Control buttons • For controlling the motor feeder, freely assignable
• Front
For connecting a memory module, an addressing plug, or a PC cable for
parameterization purposes
• Rear face
For connecting a cable to the basic unit or the expansion module
