Siemens SIMOCODE pro V MR

Technical data
15.7 Technical data of the multifunction module
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
359
Technical data of the multifunction module
Connection
• Tightening torque
TORQUE: 5.2 LB.IN to 7.0 LB.IN
0.6 Nm to 0.8 Nm
• Connection cross sections
- Solid 2 x0.5 mm
2
to 1.5 mm
2
; 1 x 0.5 mm
2
to 2.5 mm
2
2 x AWG 20 to 16 / 1 x AWG 20 to 14
- Finely stranded with end
sleeve
2 x 0.5 mm
2
... 1.0 mm
2
; 1 x 0.5 mm
2
... 2.5 mm
2
