Siemens SIMOCODE pro V MR

Technical data
15.6 Technical data of the expansion modules
SIMOCODE pro
346 System Manual, 05/2019, A5E40507475002A/RS-AD/004
15.6 Technical data of the expansion modules
15.6.1 Technical data of the digital modules
Technical data of the digital modules
Mounting
Snap-mounted onto 35-mm standard mounting rail or screw-mounted
using additional push-in lugs
Display
• Green "READY" LED • Continuous light: "Ready for operation"
• Flashing: "No connection to basic unit"
System interfaces
For connecting to a basic unit, an additional expansion module, a current
measuring module or a current / voltage measuring module or the operator
panel
Control circuit
Rated insulation voltage U
i
300 V (at pollution degree 3)
Rated impulse withstand voltage U
imp
4 kV
Relay outputs
• Number
2 monostable or bistable relay outputs (depending on the type)
• Function
Isolated NO contacts (NC contact response parameterizable via internal
signal conditioning), relay outputs all with connection to common potential,
freely-assignable to control functions (e.g. line, star or delta contactor or
operating state status information).
• Stipulated short-circuit protection for
auxiliary contacts (relay outputs)
• Fuse links, operating class gL/gG 6 A, quick-response 10 A
(IEC 60947-5-1)
• Miniature circuit breaker 1.6 A, C characteristic (IEC 60947-5-1)
• Miniature circuit breaker 6 A, C characteristic (I
k
< 500 A)
• Rated uninterrupted current • 5 A
• 6 A at max. +50 °C
• Rated switching capacity
AC-15 6 A / 24 V AC;
6 A / 120 V AC;
3 A / 230 V AC
DC-13 2 A / 24 V DC;
0.55 A / 60 V DC;
0.25 A / 125 V DC
