Description of system components
8.9 Fail-safe digital module (DM-F)
SIMOCODE pro
150 System Manual, 05/2019, A5E40507475002A/RS-AD/004
From a non-safety-related perspective, the DM-PROFIsafe module comprises:
Table 8- 6 Inputs, outputs and voltage supply to the digital module Fail-safe PROFIsafe
(DM-F PROFIsafe)
4 non-safety-related digital
24 V DC 2 non-safety-related monostable
For the 24 V DC power supply, always use an SELV or PELV power supply unit!
Surge suppressors are required for inductive loads!
