Compartment identification
9.1 Applications and advantages of compartment identification
SIMOCODE pro
160 System Manual, 05/2019, A5E40507475002A/RS-AD/004
Figure 9-1 Compartment identification
Basic units SIMOCODE pro C (3UF7000*) and basic units SIMOCODE pro V (3UF7010*)
to E08, V3.0
These basic units do not support the initialization module and start with the internal
parameters.
A configuration such as the one shown above ensures
● that the parameters, device addressing, and I&M data of the initialization module are
downloaded to the SIMOCODE basic unit during device start-up of SIMOCODE pro
● the parameters, device addressing, and I&M data are additionally written to the
initialization module when parameterizing SIMOCODE pro
This makes it simple for a user to change a withdrawable module without having to deal with
further details of parameterization or address assignment.
