Mounting, wiring, connecting, system interfaces, configuration guidelines
12.3 System interfaces
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
241
Sequence for connecting cables to the system interface
Proceed as follows:
Table 12- 25 Connecting to the system interface
1 Place the plug in the plug shaft, keeping it is as straight as possible. Ensure the locking
mechanisms of the connector slot audibly snap onto the connector enclosure.
System interfaces not in use can be closed using the system interface cover.
Figure 12-36 Sequence for connecting cables to the system interfaces
