Technical data
15.3 Technical specifications of the SIMOCODE pro V PN / pro V PN GP / pro V EIP basic units
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
339
Technical specifications of the SIMOCODE pro V PN / pro V PN GP / pro V EIP basic units
Rated switching capacity
• AC-15:
6 A / 24 V AC;
6 A / 120 V AC;
3 A / 230 V AC
• DC-13:
2 A/24 V DC;
0.55 A / 60 V DC;
0.25 A / 125 V DC
Contact rating of the auxiliary contacts
according to UL
B300/R300
Electrical durability (operating cycles)
Typical: 100 000
Mechanical durability (operating cycles)
Typical: 10 000 000
Inputs (binary)
4 inputs connected to common potential that are supplied via the device
electronics (24 V DC) for measuring process signals (e.g. local control
station, key-operated switch, limit switch, etc.), freely-assignable to
control functions.
24 V DC
Cable lengths (single)
Input characteristic
300 m
Type 1 according to EN 61131-2
Thermistor motor protection (PTC binary)
Total cold resistance
≤ 1.5 kOhm
Response value
3.4 kOhm to 3.8 kOhm
Return value
1.5 kOhm to 1.65 kOhm
Sensor short-circuit response value
< 9 ohm
Cable lengths (single), conductor cross
sections:
250 m: 2.5 mm
2
150 m: 1.5 mm
2
50 m: 0.5 mm
2
Dry-running protection for centrifugal pumps by active power monitoring
(for 3UF7011-1A.00-0 and 3UF7013-1A.00-0 basic units)
Trip level – active power 0 - 750000 W (default setting: 0)
Delay time during pump operation 0 s ... 10 s
Start-up bridging time when starting pump
0 s ... 60 s
Connection
Tightening torque
TORQUE: 7 lb.in - 10.3 lb.in; 0.8 Nm - 1.2 Nm
Connection cross sections
• Solid
2 x 0.5 mm
2
- 2.5 mm
2
; 1 x 0.5 mm
2
- 4 mm
2
;
2 x AWG 20 to 14 / 1 x AWG 20 to 12
• Finely stranded with end sleeve
2 x 0.5 mm
2
- 1.5 mm
2
; 1 x 0.5 mm
2
- 2.5 mm
2
;
2 x AWG 20 to 16 / 1 x AWG 20 to 14
