Technical data of the DM-F Local digital module
Flickering yellow
Configuration error
"6"
OFF
Cascading input 1, automatic start
Yellow
Cascading input 1, monitored start
Flashing yellow
Configuration mode waiting for confirmation
Flickering yellow
Configuration error
"7"
OFF
With startup testing
Yellow
Without startup testing
Flashing yellow
Configuration mode waiting for confirmation
Flickering yellow
Configuration error
"8"
OFF
Automatic starting after power failure
Yellow
No automatic starting after power failure
Flashing yellow
Configuration mode waiting for confirmation
Flickering yellow
Configuration error
DIP switch
for setting safety functions
"SET / RESET" button
• Application of parameters set via DIP switch
• Resetting of faults (also possible via "TEST/RESET" button on basic unit)
Inputs with safety relay
function
2 sensor inputs 24 V DC (Y12, Y22)
• Supply via terminal T1 and T2 with cross-circuit detection or external supply (static
+24 V DC) without cross-circuit detection
• Functions parameterizable via DIP switch
1 start signal input 24 V DC (Y33)
• For monitored reconnection of the relay enabling circuits after a safety-related trip
• Supply via terminal T1 with/without T3 (static +24 V DC) without cross-circuit detection
1 cascading input 24 V DC (1)
• For use in connection with a higher-level safety relay
• Supply via terminal T3 (static +24 V DC)
1 feedback circuit input 24 V DC (Y34)
• For contactor monitoring of the motor and incoming supply contactors via series-connected
auxiliary switch normally-closed contacts
• Supply via terminal T2 with/without T3 (static +24 V DC) without cross-circuit detection
Cable length (single)
1500 m
Input characteristic
Type 2 according to EN 61131-2
