● The DI/DO 9 to 11 can be used as high-speed inputs for measuring inputs or for external
zero marks.
The assignment of the inputs is not fixed, and the special use is activated in the
SIMOTION SCOUT engineering system.
● All
four digital inputs/outputs can be used as freely addressable inputs or as homing inputs.
When parameterizing the DI/DOs as digital outputs, these can be used as freely addressable
outputs.
Note
Shielded cables are required when connecting measuring inputs or external zero marks for
optimal noise immunity.
Additional references
For
information on configuring the DI/DOs as freely addressable I/Os or as measuring inputs,
see the
SIMOTION D4x5
Commissioning and Hardware Installation Manual.
For information on the configuration and function of the measuring input, output cam, and cam
track technology objects, refer to the
SIMOTION Output Cams and Measuring Inputs
Function
Manual.
7.4.2.4 Power supply
Application
This interface is provided exclusively for connection of an external power supply.
Note
When using external power supplies (e.g. SITOP), the ground potential must be connected
with the protective ground terminal (PELV).
Features of the interface
Table 7-17
Interface X124
Features Type
Connector type 4-way screw-type terminal
Connectable cable types and conductor cross-
sections
Rigid 0.2 mm² … 2.5 mm²
Flexible 0.2 mm² … 2.5 mm²
Supplementary system components
7.4 Controller Extension CX32
SIMOTION D4x5
Manual, 04/2014 101
