Available spare parts and accessories
8
Table 8-1
Spare parts and accessories
Parts for SIMOTION D4x5 Order No. Accessorie
s
Spare parts
1-GB CompactFlash card (CF card)
With drive software and SIMOTION Kernel (latest CF card at the
time of writing)
6AU1400-2PA03-0AA0 x
PROFIBUS RS485 bus connector with angular cable outlet (35
°)
With screw-type terminals, max. transmission rate 12 Mbit/s
- without PG/PC interface
- with PG/PC interface
6ES7972-0BA41-0X40
6ES7972-0BB41-0X40
x
x
PROFIBUS Fast Connect RS485 bus connector with angular
cable outlet (35°)
with insulation displacement terminals, max. transmission rate
12 Mbit/s
- without PG/PC interface
- with PG/PC interface
6ES7972-0BA60-0XA0
6ES7972-0BB60-0XA0
x
x
Fan/battery module incl. battery
(can be used with D425/D435/D445/D445‑1)
In the case of the SIMOTION D445, the fan/battery module is
already included in the scope of delivery.
(optional for D425/D435; required for D445)
6FC5348-0AA01-0AA0 x x
Double fan/battery module incl. battery
(can be used with D445‑1)
In the case of the SIMOTION D445‑1, the double fan/battery
module is already included in the scope of delivery.
6FC5348-0AA02-0AA0 x
3 V lithium battery for fan/battery module 6FC5247-0AA18-0AA0 x
Spacers for D425 and D435
Kit, 2 units
6SL3064-1BB00-0AA0 x
Terminals for digital inputs/outputs (X122 and X132) 6SL3064-2AB00-0AA0 x
Terminal kit contains
●
3 x I/O connectors for X122/X132
● 1 x 24 V connector for X124
● 5 x DRIVE‑CLiQ blanking cover for X100-X105
6SL3064-8MA00-0AA0 x
Power supply connector (X124) 6SL3065-2AA00-0AA0 x
Option slot protective cover 6SL3064-3CB00-0AA0 x
Dust protection filler plugs for sealing unused DRIVE‑CLiQ,
Ethernet or PROFINET ports
Filler plugs (50 pcs)
6SL3066-4CA00-0AA0 x x
Blanking cover for the protection of the operator controls 6SL3064-3BB00-0AA0 x
