2.8 CompactFlash card
2.8.1 Usage and function of the CompactFlash Card
The CompactFlash card (CF card) is inserted in the slot with the designation CF (X109
interface).
5HFHVVHGJULSRIWKH&RPSDFW)ODVKFDUG
%ODQNLQJSODWH
Figure 2-7 Slot for CompactFlash card
The CF card does not extend beyond the housing. An ergonomic recessed grip enables the
CF card to be removed.
