Note
SIMOTION D445-1 must be operated with a double fan/battery module for heat dissipation.
Without this module, the control unit will not start up and cannot be commissioned.
You will find information on how to install the double fan/battery module in "Spare Parts/
Accessories," Section Installing the fan/battery module
(Page 85).
Note
SIMOTION
D445-1 comes with pre-assembled spacers. These can be removed if necessary.
2.7 Nameplates
Side-mounted type plate
The figure below shows all the information included on the type plate located on the side of
the unit.
0RGXOHGHVLJQDWLRQ
2UGHU1R
6HULDOQXPEHU
&7LFN
F8/XV
+DUGZDUHYHUVLRQ
Figure 2-5 D425 type plate
Note
The
information contained in each field of the type plate on your actual Control Unit may differ
from that presented in this manual (for example, a later product version, approvals and marks
that have not yet been earned, etc., may be shown).
Description
2.7 Nameplates
SIMOTION D4x5
Manual, 04/2014 33
