Interfaces
4
4.1 Interface overview
This section describes the interfaces of the SIMOTION D4x5.
Available interfaces
Table 4-1
Overview of available interfaces
Interface Name Connector type
DRIVE-CLiQ interface X100 DRIVE-CLiQ socket
DRIVE-CLiQ interface X101 DRIVE-CLiQ socket
DRIVE-CLiQ interface X102 DRIVE-CLiQ socket
DRIVE-CLiQ interface X103 DRIVE-CLiQ socket
DRIVE-CLiQ interface X104 (D445/D445‑1
only)
DRIVE-CLiQ socket
DRIVE-CLiQ interface X105 (D445/D445‑1
only)
DRIVE-CLiQ socket
Ethernet interface IE1/OP X120 RJ45 socket connector
Ethernet interface IE2/NET X130 RJ45 socket connector
Digital inputs/outputs X122, X132 Micro Combicon, 2x12-pin
Power supply connector X124 Combicon, 4‑pin
PROFIBUS DP1 interface X126 9-pin SUB-D socket
PROFIBUS DP2/MPI interface X136 9-pin SUB-D socket
Measuring sockets (T0, T1, T2, and G) X131 - X134 Sockets
SIMOTION CompactFlash plug-in X109 CompactFlash Card connector
Fan/battery module interface X190 Fan/battery module
1. USB interface X125 USB socket
2. USB interface X135 USB socket
Option slot Sockets
SIMOTION D4x5
Manual, 04/2014 49
