The SIMOTION D445‑1 must always be operated with a double fan/battery module.
NOTICE
Higher operating temperature if ventilation clearances are too small
The ventilation clearances of 80 mm above and below the components must be observed.
The unit protects itself from overheating by shutting down.
The
ventilation clearance is measured from the lower edge of the module, i.e. the fan/battery
module is not included in the dimension.
6.4 CAD data, dimension drawings, and circuit-diagram macros
Dimension drawings and CAD data
Dimension drawings, as well as 2D and 3D CAD data, can be generated in commonly used
formats using CAD CREATOR.
For further information, see the following Internet address (http://
support.automation.siemens.com/WW/view/en/30559271).
Circuit-diagram macros
EPLAN
circuit-diagram macros are available for SIMOTION D4x5. The macros are supported
when you create circuit diagrams.
The following address will take you to the macros (
http://support.automation.siemens.com/
WW/view/en/31622426).
Dimension drawings
6.4 CAD data, dimension drawings, and circuit-diagram macros
SIMOTION D4x5
80 Manual, 04/2014
