Operator control (hardware)
3
3.1 Overview of operator control and display elements
The
following figure shows the arrangement of the operator control and display elements of a
SIMOTION D4x5.
2SHUD
WRUFRQWURODQG
GLVSOD\HOHPHQWV
Figure 3-1 Position of operator control and display elements
The operator control and display elements are described in detail below.
The arrangement of the operator control and display elements will depend on the specific
SIMOTION D4x5 device version.
SIMOTION D4x5
Manual, 04/2014 41
