Terminal Function Technical specifications
G
Max. power consumption per digital output: 0.5 A
Max. current via bridges in the connector: 20 A
Ground
G Ground
Table 7-4 X424 wiring
Features Type
Connector type 4-way screw-type terminal
Connectable cable types and conductor cross-
sections
Rigid 0.2 mm² … 2.5 mm²
Flexible 0.2 mm² … 2.5 mm²
Flexible, with wire-end ferrule without plastic
sleeve
0.2 mm² … 2.5 mm²
Flexible, with wire-end ferrule with plastic
sleeve
0.2 mm² … 1.5 mm²
AWG / kcmil 22 … 12
Stripped length 6 … 7 mm
Tool Screwdriver 0.5 x 3 mm (M2.5)
Tightening torque 0.4 to 0.5 Nm
Max. current carrying capacity, incl. loop-through 20 A (15 A per UL/CSA)
Max. cable length 10 m
Features
Two "+" terminals and two "G" terminals are available. These are jumpered in the connector.
This loops through the power supply.
This power supply is only required for the digital outputs.
The option slot of the D4x5 Control Unit also provides the following power supplies:
●
Electronic power supply of the TB30
● Supply of the analog inputs and outputs.
The power supply of the digital outputs and the electronic power supply of the Control Unit are
isolated.
7.3.3.4 Digital inputs/outputs
Table 7-5 Terminal block X481
Terminal Designation
1)
Technical specifications
1 DI 0 Voltage: -3 V to 30 V
Typical current consumption: 10 mA at 24 VDC
Ground reference: X424 (G terminal)
2 DI 1
Supplementary system components
7.3 TB30 terminal board
SIMOTION D4x5
Manual, 04/2014 91
