Table 7-33 Interface overview
Interface Quantity
Digital inputs 8
Bidirectional inputs/outputs 4
Relay outputs with changeover contact 2
Analog inputs 2
Analog outputs 2
Temperature sensor input (KTY84-130 or PTC) 1
NOTICE
Overheating if ventilation clearances are too small
Insufficient ventilation clearances result in overheating and therefore in more failures and a
shortened life of the component.
Maintain 50 mm ventilation clearances above and below the component.
Additional references
You will find detailed information about the TM31 in the
●
SINAMICS S120 Control Units and Additional System Components
Manual
●
SIMOTION D4x5
Commissioning and Hardware Installation Manual
7.7 Terminal module TM41
Characteristics of the TM41
With the TM41 Terminal Module, the number of available digital inputs/digital outputs and the
number of analog inputs within a drive system can be expanded. In addition, the TTL output
can be used for encoder emulation. The TM41 is connected via DRIVE-CLiQ.
The TM41 contains the following terminals:
Table 7-34 Interface overview
Type Quantity
Digital inputs 4
Digital inputs/outputs 4
Analog inputs 1
TTL encoder output 1
Supplementary system components
7.7 Terminal module TM41
SIMOTION D4x5
114 Manual, 04/2014
