7.3 TB30 terminal board
7.3.1 Description
The TB30 Terminal Board is a terminal expansion module for SIMOTION D4x5. It is plugged
into the option slot of the D4x5 Control Unit.
Table 7-2 Interface overview of the TB30
Type Quantity
Digital inputs 4
Digital outputs 4
Analog inputs 2
Analog outputs 2
7.3.2 Safety information for the TB30
NOTICE
Damage to the TB30 caused by electric fields or electrostatic discharge
Option boards are ESD-sensitive components.
De-energize the SIMOTION D4x5 device before inserting or removing the option board.
SIMOTION D4x5 is in a de-energized state when all the LEDs are OFF.
Observe ESD guidelines; for details, see Section
ESD guidelines (Page 123).
Supplementary system components
7.3 TB30 terminal board
SIMOTION D4x5
88 Manual, 04/2014
