7.3.3.6 Working with analog inputs
The following reference contains more information about analog inputs:
●
/IH1/
SINAMICS S120 Commissioning Manual.
● /GH1/ SINAMICS S120 Control Units and Additional System Components Manual.
7.3.3.7 Commissioning
Information about commissioning can be found in the
SIMOTION D4x5 Commissioning and Hardware Installation Manual.
7.3.4 Technical Specifications
Table 7-9 Technical data of the TB30
Unit Value
Electronic power supply:
- Voltage
- Current via the option slot of the D4x5
(without digital outputs)
- Power loss
V
DC
A
DC
W
24 (20.4 ... 28.8)
0.05
<3
Response time The response time of digital inputs/outputs and analog inputs/outputs depends on
the evaluation on the Control Unit (see function diagram).
Reference: SINAMICS
S120/S150 Parameter Manual, Chapter "Function diagrams"
Dimensions (H x W x D), approx. mm 25 x 95 x 143
Weight g 100
7.4 Controller Extension CX32
7.4.1
Overview of CX32
Properties
The CX32 is a module in SINAMICS S120 booksize format. The CX32 allows scaling for the
drive-end computing performance of the SIMOTION D435, D445 and D445-1 Control Units.
Each CX32 can control up to 6 additional servo axes, 4 vector axes or 8
V / f axes.
The controller extension has 4 DI, 4 DI/DO and 4 DRIVE‑CLiQ interfaces.
Supplementary system components
7.4 Controller Extension CX32
SIMOTION D4x5
94 Manual, 04/2014
