Drive quantity structures
If one or more CX32 modules are being used on a SIMOTION D435 or D445/D445‑1, the
number
of drives that can be used on the SINAMICS Integrated is reduced by one. This gives
the following quantified volumes:
SIMOTION V4.1/V4.2 (SINAMICS V2.5/V2.6)
Table 7-10 SIMOTION V4.1/V4.2 (SINAMICS V2.5/V2.6) quantity structure
SINAMICS
Integrated
1. CX32 2. CX32 3. CX32 4. CX32
SERVO D435 5+1 (5 drives+
1 ALM
1)
)
6+1 6+1 ----- -----
SERVO D445/
D445‑1
5+1 6+1 6+1 6+1 6+1
VEKTOR D435 3+1 4+1 4+1 ----- -----
VECTOR D445/
D445‑1
3+1 4+1 4+1 4+1 4+1
V
/
f
D435 7+1 8+1 8+1 ---- ----
V
/
f
D445/D445-1 7+1 8+1 8+1 ---- ----
1)
ALM
= Active Line Modules; Basic Line Modules (BLM), and Smart Line Modules (SLM) can
also be used.
SIMOTION V4.0 HF2 (SINAMICS V2.4)
Table 7-11 SIMOTION V4.0 HF2 (SINAMICS V2.4) quantity structure
SINAMICS
Integrated
1. CX32 2. CX32 3. CX32 4. CX32
SERVO D435 5+1 (5 drives+
1 ALM
1)
)
6+0 6+0 ----- ------
SERVO D445 5+1 6+0 6+0 6+0 -----
VEKTOR D435 3+1 4+0 4+0 ----- -----
VEKTOR D445 3+1 4+0 4+0 4+0
1)
ALM
= Active Line Modules; Basic Line Modules (BLM), and Smart Line Modules (SLM) can
also be used.
Note
Mixed operation of servo and vector-controlled drives
Mixed
operation of servo and vector-controlled drives is not possible on a CX32. Therefore,
drives on a CX32 must be operated in servo or in vector mode only. As with the SIMOTION
D4x5, mixed operation of servo and
V
/
f
-controlled drives is possible on a CX32.
V/f-controlled drives
A maximum of 8
V
/
f
-controlled drives are supported by each CX32.
Supplementary system components
7.4 Controller Extension CX32
SIMOTION D4x5
Manual, 04/2014 95
