Available Z options / licenses for CF cards
●
Axis licenses
– Pxx POS license and number (e.g. P02 = 2x POS license)
– Gxx GEAR license and number (e.g. G03 = 3 x GEAR licenses)
– Cxx CAM license and number (e.g. C01 = 1x CAM license)
● MultiAxes package
– M00 MultiAxes package license (platform independent)
– M42-MultiAxes Package license for D425
– M43-MultiAxes Package license for D435 (incl. D425)
– M44-MultiAxes Package license for D445/D445-1 (incl. D425 and D435)
● MultiAxes and SAFETY INTEGRATED EXTENDED Package
– S42/S43/S44 license as M42/M43/M44 license, but also including licensing of the Safety
Integrated Extended Functions for all drives on SINAMICS Integrated/CX32
● TControl temperature control
– Txx TControl license and number (e.g. T03 = 3x TControl licenses)
● SIMOTION IT
– D00 - SIMOTION IT DIAG license (no longer under license as of SIMOTION V4.2)
– X00 - SIMOTION IT OPC XML‑DA license (no longer under license as of SIMOTION
V4.2)
– J00 - SIMOTION IT Virtual Machine license for Java applications
● Safety functions
– Fxx-License for SINAMICS Safety Integrated Extended Functions (for integrated
SINAMICS drives for SIMOTION D4x5 and CX32) (e.g. F02=2x Safety Integrated
Extended Functions).
Note
CF cards provided as part of a MultiAxes bundle do not have this additional labeling option.
Depending
on the version, a MultiAxes bundle consists of a SIMOTION D425, D435 or D445/
D445‑1 plus a CF card with a "MultiAxes Package" license for the relevant SIMOTION D
hardware.
2.8.3 Data matrix code on CF card
SIMOTION D CompactFlash Cards have a machine-readable identification in the form of a
data matrix code (2D code).
Reader units that support the data matrix code in accordance with ECC 200 are suitable for
reading the code used here.
Description
2.8 CompactFlash card
SIMOTION D4x5
38 Manual, 04/2014
