Analysis
Example of a data string from the reader unit:
1P6AU1400-2PA01-0AA0‑Z+ST-WOQB02934+30SST0B8365550000079001.
Table 2-7
Machine-readable identification via 2D code
Feature Property
Order number
("1P" identifier to identify the products)
6AU1 400-2PA01-0AA0‑Z
Serial number
("S" identifier, item number)
T‑WOQB02934
HW serial number
("30S" identifier)
ST0B8365550000079001
In addition to the "serial number", CompactFlash Cards also have a "HW serial number".
If
licenses are purchased for functions under license, a "license key" is generated from the HW
serial number of the CompactFlash Card and the serial number of the purchased licenses,
which is only valid for the respective CompactFlash Card.
The data required for the licensing can be read by reader unit via the bar codes on the license
certificates (Certificate of License "CoL") and the 2D code on the CompactFlash Card in order,
for example, to automate the licensing process.
Description
2.8 CompactFlash card
SIMOTION D4x5
Manual, 04/2014 39
