NOTICE
Overheating if ventilation clearances are too small
Insufficient ventilation clearances result in overheating and therefore in more failures and a
shortened life of the component.
Maintain 50 mm ventilation clearances above and below the component.
Additional references
You will find detailed information about the TM41 Terminal Module in the
●
SINAMICS S120 Control Units and Additional System Components
Manual
●
SIMOTION D4x5
Commissioning and Hardware Installation Manual
7.8 Terminal Module TM54F
Characteristics of the TM54F
The TM54F Terminal Module is a terminal expansion module for snapping on to a DIN EN
60715 mounting rail. The TM54F offers safe digital inputs and outputs for control of Safety
Integrated functions of SINAMICS. The TM54F Terminal Module is supported by SIMOTION
D4x5 from version V4.1 SP1 and higher.
No more than one TM54F can be assigned to each drive control (SINAMICS Integrated of a
D4x5, CX32, CU320, etc.). Connection is via DRIVE‑CLiQ. Each drive control must have its
own dedicated TM54F.
Additional nodes (e.g. TMxx, SMxx, MMxx) can be connected to the same DRIVE‑CLiQ line.
TM54 is equipped with the following terminals:
Table 7-35 Interface overview
Type Quantity
Fail-safe digital outputs (F‑DO) 4
Fail-safe digital inputs (F‑DI) 10
Sensor
1)
power supplies, dynamic response
supported
2)
2
Sensor
1)
power supplies, no dynamic response 1
Digital inputs for testing the F‑DO with test stop 4
1)
Sensors: Fail-safe devices for commanding and detecting, such as emergency stop
pushbuttons and safety locks as well as position switches and light arrays / light curtains.
2)
Dynamic
response: The sensor power supply is switched on and off during test stop for testing
the sensors, the cable routing, and the evaluation electronics of TM54F.
Supplementary system components
7.8 Terminal Module TM54F
SIMOTION D4x5
Manual, 04/2014 115
