Parameter Values
Degree of protection according to EN 60529
(IEC 60529)
IP20
Atmospheric pressure 700 ... 1060 hPa
Note
The
components must be protected against conductive contamination, e.g. by installing them
in a control cabinet with degree of protection IP54 according to IEC 60529 or NEMA 12.
If conductive contamination can be excluded at the installation site, a lower degree of cabinet
protection may be permitted.
See Residual risks of power drive systems (Page 16).
Integrated drive control
Table 7-23
Controls for integrated drives
Data SIMOTION CX32
Max. number of axes for integrated drive control
(servo/vector/
V
/
f
)
6 / 4 / 8 (alternative)
Drive control based on SINAMICS S120 CU320,
firmware version V2.x
Communication
Table 7-24
Interface communication
Data SIMOTION CX32
DRIVE‑CLiQ interfaces 4
General technical data
Table 7-25 Technical data (general)
Data SIMOTION CX32
Power supply
●
Rated value
● Permissible range
24 V DC
(20.4 ... 28.8 V)
Current consumption, typically
1)
800 mA
Starting current, typ. 1.6 A
Power loss 20 W
1)
With no load on inputs/outputs, no 24 V supply via DRIVE‑CLiQ interfaces
Supplementary system components
7.4 Controller Extension CX32
SIMOTION D4x5
Manual, 04/2014 105
