Siemens SINUMERIK 828D Service Manual

Service cases - hardware
4.3 SINAUT modem
Hardware and Software
Service Manual, 03/2011, 6FC5397-5DP40-0BA0
89
5. Press the upper section of the SIM card holder downwards. Ensure that the sloped corner
of the SIM card clicks into place.
6. Using your fingernail or a suitable object, slide the upper section of the SIM card holder
approximately 2 mm in the direction of the arrow to the right in order to lock the SIM card
holder.
7. The SIM card is then firmly locked in the SIM card holder:

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
