5 Configuring 11.92
5.13 FB 139 Data distributor
Identifications in the dynamic buffer
Tool disabled
(DB 152 bit 10)
User bit 2
Tool life/No. of workpieces
reached (DB 152 bit 0)
User bit 1
DW 32
DW 33
The bits are reset in the magazine table if ASCII code 0 = 30H and are set if ASCII code
1 = 31H. The standard bits in word 1 are defined in DB 152 (identification bits of the
magazine table).
Valid for "Write data" only.
If the ASCII code of one or more of the four signals is not equal to 30H or 31H, the
respective signals maintain their status.
The user bits are assigned by means of the following machine data specifications:
Bit number
Target DB number
User bit 1: defined via MD 2078 = DB 61, DW 78
Bit number
Target DB number
User bit 2: defined via MD 2079 = DB 61, DW 79
Bit numbering starts at 0 to 15.
When defining the machine data, it should be ensured that the data are entered in KF
format. The value to be entered is derived from the following equation:
MD 2078/MD 2079 = bit No.
*
256 + target DB No.
The data word address of the target locator No. is determined and specified by the data
distributor via the current magazine and locator No.
The target specifications must be entered by the user.
b) The identifications are coded bitwise
– For source = computer : MD bit 7001.7 = DB 64 D0.7 = 1
– For source = tape : MD bit 7011.7 = DB 64 D5.7 = 1
16 bits
16 bits
DW 32
DW 33
Identifications in the dynamic buffer
5–48
© Siemens AG 1991 All Rights Reserved 6FC5 197-0AA40-1BP1
SINUMERIK 840/880 (PJ)
