Siemens SINUMERIK 840 Planning Guide

10 Data Fields 11.92
10.1.4 Assignment of the data words/bits of the submagazine-specific user interface
10.1.4 Assignment of the data words/bits of the submagazine-specific
user interface
(channel DB 10 to channel DB 25 SINUMERIK 880/880 GA2)
(channel DB 10 to channel DB 13 SINUMERIK 840/840C)
15 14 13 12 11 10 9 8
76543210
Job
initiation
coordination
DW
Sup-
press
routing
DL 63
Bit No.
Coordi-
nation
error
H word
is valid
T word
is valid
DR 63
No. of the source channel
DW 64
T word (decade 4...7)
DW 65
T word (decade 0...3)
DW 66
Extended H address
DW 67
H word (decade 4...7)
DW 68
Reference data
of the source
channel
H word (decade 0...3)
DW 69
10–8 © Siemens AG 1991 All Rights Reserved 6FC5 197-0AA40-1BP1
SINUMERIK 840/880 (PJ)
