11.92 5 Configuring
5.1 General
5 Configuring
5.1 General
The tool management software package is divided into two areas: basic functions and
functions that can be called up and initialized by the user, if required. The blocks called by the
user PLC program are described below.
The function blocks FB 117 "Create magazine table" and FB 123 "Tool selection on T change
signal" are not described here. Both blocks are initialized automatically via machine data and
called unconditionally by the user. FB 117 "Create magazine table" is called in startup OB 20.
FB 123 "Tool selection T change signal" is called in OB 1. FB 139 "Data distributor", which
will be described in Section 6.1.8, is also called in OB 1.
The function blocks must not be initialized via data blocks. Flag bytes
FY 224 to FY 255 must not be used for parameter assignment.
List of function blocks
FB 111: Neutral tool search
FB 112: Search for empty location without presetting
FB 118: Standard tool size
FB 120: Unload onto tape (SINUMERIK 880/880 GA2 only)
FB 120: Reserved (SINUMERIK 840/840C only)
FB 121: Measuring
FB 122: Search for empty location with presetting
FB 128: Transfer
FB 133: Direction selection
FB 135: Provide D No. after tool change
FB 139: Data distributor
FB 155: Tool input via tape
FB 156: Tool life monitor/prewarning limit
FB 157: Monitor for number of pieces/prewarning limit
FB 197: Load tool list (milling version)
FB 198: Exchange list, generate list of missing tools (milling version)
FB 199: First in first out (milling version)
FB 197: Load tool list (turning version)
FB 198: Exchange list, generate list of missing tools (turning version)
FB 199: First in first out (turning version)
FX 7: Simulation of a part program (SINUMERIK 880/880 GA2 only)
FX 8: Tool size EPROM
© Siemens AG 1991 All Rights Reserved 6FC5 197-0AA40-1BP1 5–1
SINUMERIK 840/880 (PJ)
