Siemens SINUMERIK 840 Planning Guide

9 Examples 11.92
9.1.3 Description of the PLC program
9.1.3.6 Magazine table (referring to this example)
Structure of the magazine table:
Data block Comment
DB 150 Status words DBZW
DB 151 Identifications 1 DBZW+1
DB 152 Identifications 2 DBZW+2
DB 153 Identifications 3 DBZW+3
DB 154 ID number
DB 155 ID number
DB 156 Duplo number
DB 157 Status bits User DB
DB 158 User DB
DB 159 User DB
DB 160 User DB
DB 161 User DB
DB 162 User DB
DB 163 User DB
DB 164 Reference data
DB 165 Reference data
DB 166 Reference data
DB 167 Reference data
9.1.3.7 TO memory assignment (referring to this example)
TO memory assignments:
TO area Contents
P0 User
P1 Type
P2 Geometry L1
P3 Geometry L2
P4 Geometry radius
P5 Wear L1
P6 Wear L2
P7 Wear radius
P8 Additional compensation L1
P9 Additional compensation L2
P10 Unassigned
P11 Unassigned
P12 Unassigned
P13 Specified tool life
P14 Tool life
P15 Prewarning limit, tool life
9–32 © Siemens AG 1991 All Rights Reserved 6FC5 197-0AA40-1BP1
SINUMERIK 840/880 (PJ)

Siemens SINUMERIK 840 Specifications

General

Control Type	CNC
Axes	Up to 31
Display	TFT color display
PLC	Integrated
HMI	SINUMERIK Operate
Communication Interfaces	Ethernet, PROFIBUS, PROFINET
Type	CNC system
Programming Languages	G-code
Max Number of Channels	10
Operating Temperature	0 to 45 °C
Relative Humidity	Up to 95% (non-condensing)
Protection Class	IP54 (front panel)
