8 Service and Diagnostics 01.91
8.2 Error messages resulting in an abort of the function during loading
8.2 Error messages resulting in an abort of the function during
loading
Package 5 Data distributor
3200 1: Job initiation during valid job processing
3201 2: Illegal command code
3202 3: Magazine not available
3203 4: Magazine location not available
3204 5: Cutting edge number not available
3205 6: Number of cutting edges to be loaded does not correspond to setup
data
3206 7: Cutting edges not loaded in ascending order
3207 8: Reloading: Tool identified by ID and duplo number not found
3208 9: Out of area on TO data access
3209 10: TO memory full
3210 11: Abort due to power failure; tool data entered have been deleted
3211 12: Magazine and/or locator number changed while loading several cutting
edges
3212 13: Insufficient number of free adjacent locations (only for magazines
without configuration)
3213 14: No further tool to be reported in the magazine
3214 15: Invalid presetting of reference list
3215 16: Reloading into tool buffer not possible
3216 17: D No. has already been entered
3217 18: Magazine location disabled, reserved or occupied by another tool
3218 19: No loading memory defined
3219 20: Tool buffer is not allocated to any magazine/channel
global tool buffer
3220 21: Loading with operator guidance not permissible (DB 146, D 1.0 = 1)
3221 22: No ready signal from operator panel
3222 23: Loading with operator guidance was aborted
(negative acknowledgement DB 146, D 1.1 = 1)
3223 24: Machine data "Magazine No. for loading with operator guidance" not
defined (DB 146, DW 136 = 0)
3224 25: Magazine is not fictitious magazine
3225 26: No empty location for fictitous magazine has been found
3226 27: Error occurred during user bit routing
8–2 © Siemens AG 1991 All Rights Reserved 6FC5 197-0AA40-1BP1
SINUMERIK 840/880 (PJ)
