10 Data fields 01.91
10.2.4 User interface
10.2.4 User interface
Caution: Except for the signal D 63.15 "Suppress routing", D 63.7 "Coordination error", data
word DW 76 "Current actual position" and the user interface, only read access is possible for
the submagazine-specific user interface.
DW
Job initiation
coordination
15 14 13 12 11 10 9 8
76543210
Bit No.
DL 63
H word
is valid
T word
is valid
Sup-
press
routing
DR 63
Coordi-
nation
error
COORDINATION ERROR IN T AND/OR H WORD ROUTING TO SUBMAGAZINE-
SPECIFIC INTERFACE D 63.7
"1" signal: If a T and/or H word (from the NC program) is to be routed to the submagazine-
specific user interface (DW 64 to DW 69) although the search is not yet terminated
for a T word already entered. As long as the signal is set, no further job is routed
to the submagazine-specific user interface by the T/H word routing. The signal
must be acknowledged by the user.
Caution: The current job is aborted and the new job is not accepted. In the
"Suppress routing" mode (D 63.15= 1), this monitor is not active.
"0" signal: No coordination error.
SUPPRESSION OF T AND H WORD ROUTING FROM CHANNEL-SPECIFIC
INTERFACE TO SUBMAGAZINE-SPECIFIC USER INTERFACE D 63.15
"1" signal: T and H words from the NC, and thus from the channel-specific interface (DW 40
to DW 45), are not routed to the submagazine-specific user interface. In this
mode, the tool selection can be controlled via the user program and search jobs
can be transferred to to the tool selection instead of the part program.
This signal must be set and reset by the user. The user must also assign
DW 64 (source channel number)!
10–26 © Siemens AG 1991 All Rights Reserved 6FC5 197-0AA40-1BP1
SINUMERIK 840/880 (PJ)
