12.91 5 Configuring
5.23 FX 7 Part program simulation
:
:
:
: L KB 1 Magazine number = 1
: T FY 120
:
: DO FX 7 SIMULATION BLOCK
NAME : SIMULAT
A-NR : KF + 1 Job number = 1
MANR : FY 210 Magazine number
ESP : F 211.0 Read-in disable
F : F 211.1 Error
:
: C DB 13 Channel DB from NC channel 4
: A F 211.0 Route read-in disable
: = D 9.6 e.g. to D 9.6
:
: AN F 211.1
: JC = WEIT ERROR EVALUATION:
: C DB 150
: L KF + 269 Set pointer DB 150 to DW 269
: JU OB 180 ( DW0)
:
: L DW 0 Read out error number
: T FW 200
: L DD 1 Read out current T number
: T MD 202 if error occurs.
:
WEIT :
:
:
:
:
5.24 FX 8 WZ-GR:EP
Presetting of tool size via EPROM
Description
With function block "WZ-GR: EP", all the magazine locations of a fictitious magazine are
preset with the tool sizes stored in a data block of the EPROM.
The tool size data must be stored in the EPROM as follows:
DW x
DW y
F F # Locations
---------------------- WZ-GR: Location 1
--------------------- WZ-GR: Location 2
--------------------- WZ-GR: Location 3
:
:
:
:
:
:
:
:
:
-------------------- WZ-GR: Location n
© Siemens AG 1991 All Rights Reserved 6FC5 197-0AA40-1BP1 5–101
SINUMERIK 840/880 (PJ)
