Siemens SINUMERIK 840 Planning Guide

9 Examples 11.92
9.1.3 Description of the PLC program
Data structure of buffer assignment in DB 146:
FRBLGZWS.
Address key 171 Comment
DW 16 Pointer change position
DW 17 Pointer loading point
DW 18 T No. change position
DW 19 T No. change position
DW 20 T No. loading position
DW 21 T No. loading position
DW 22 Locator No. change position
DW 23 Locator No. loading position
DL DR
Data structure of the magazine assignment in DB 146:
FRBLGMAG.
Address key 172 Comment
DW 24 Magazine No.
DW 25 Start-of-area pointer
DW 26 Length-of-area pointer
DW 27 Cursor pointer
DW 28 Unassigned
DW 29 Unassigned
DW 30 Unassigned
DW 31 Unassigned
DL DR
9–38 © Siemens AG 1991 All Rights Reserved 6FC5 197-0AA40-1BP1
