Siemens SINUMERIK 840 Planning Guide

11.92 9 Examples
9.1.3 Description of the PLC program
Data structure of the message display in DB 146:
FRWAHL2.
Address key 194 Comment
151413121110987654321 0
DW 80 Magazine No.
DW 81 Locator No.
DW 82 Unassigned
DW 83 Unassigned
DW 84 Unassigned
DW 85 Unassigned
DW 86 Unassigned
DW 87 Unassigned
Data structure of the message display in DB 146:
FRBASIS1., ENTLADE (SINUMERIK 880/880 GA2 only)
Address key 197 Comment
151413121110987654321 0
DW 88 Magazine No.
DW 89 Locator No.
DW 90 Cutting edge No.
DW 91 T number
DW 92 T number
DW 93 Unassigned
DW 94 Unassigned
DW 95 From magazine
To magazine
© Siemens AG 1991 All Rights Reserved 6FC5 197-0AA40-1BP1 9–41
SINUMERIK 840/880 (PJ)

Siemens SINUMERIK 840 Specifications

General

Control Type	CNC
Axes	Up to 31
Display	TFT color display
PLC	Integrated
HMI	SINUMERIK Operate
Communication Interfaces	Ethernet, PROFIBUS, PROFINET
Type	CNC system
Programming Languages	G-code
Max Number of Channels	10
Operating Temperature	0 to 45 °C
Relative Humidity	Up to 95% (non-condensing)
Protection Class	IP54 (front panel)
