Siemens SINUMERIK 840 Planning Guide

9 Examples 01.91
9.2.17 FB 178 Change tool data of magazine assignment
Block structure
Network 1
* * * * * * * * * *
– Start
Network 2
* * * * * * * * * *
– Load static signal, status word
Network 3
* * * * * * * * * *
– Evaluate cursor pointer
– Output error message
Network 4
* * * * * * * * * *
– Write R999
Network 5
* * * * * * * * * *
– Save status word
– Reset static signal
Network 6
* * * * * * * * * *
– End
9–96 © Siemens AG 1991 All Rights Reserved 6FC5 197-0AA40-1BP1
SINUMERIK 840/880 (PJ)
