Siemens SINUMERIK 840 Planning Guide

10 Data fields 02.93
10.2.2 PLC machine data words (DB 61)
Assignment of spindle machine data
To simplify the input of "low" and "high" bytes for the user, this list shows all possible
combinations.
Possible spindle machine data assignments:
Superordinate
channel
Chan-
nel
Machine data contents
1 1 4452
2 1 8448
3 1 12455
1 2 4608
2 2 8960
3 2 12800
1 3 4864
2 3 8960
3 3 13056
1 4 5120
2 4 9216
3 4 13312
1 5 5376
2 5 9472
3 5 13568
1 6 5632
2 6 9728
3 6 13824
1 7 5888
2 7 9984
3 7 14080
1 8 6144
2 8 10240
3 8 14336
1 9 6400
2 9 10496
3 9 14592
1 10 6656
2 10 10752
3 10 14848
Superordinate
channel
Chan-
nel
Machine data contents
1 11 6912
2 11 11008
3 11 15104
1 12 7168
2 12 11264
3 12 15360
1 13 7424
2 13 11520
3 13 15616
1 14 7680
2 14 11776
3 14 15872
1 15 7936
2 15 12303
3 15 16128
0 1 256
0 2 512
0 3 768
0 4 1024
0 5 1280
0 6 1536
0 7 1792
0 8 2048
0 9 2304
0 10 2560
0 11 2816
0 12 3072
0 13 3328
0 14 3584
0 15 3840
10–18 © Siemens AG 1991 All Rights Reserved 6FC5 197-0AA40-1BP1
SINUMERIK 840/880 (PJ)
