Siemens SINUMERIK 840D sl Operation/Programming

11
Examples 08/2005
11.1 Standard machinin
g
p
rocesses
11
♥ Siemens AG, 2005. All rights reserved
11-414 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Machining direction
. (from front to back)
Stock allowance
No
Limit
No
Rear cut
Yes
 Press the
softkey
9. Groove (roughing)
 Press the
Groove
softkeys
 Enter parameters:
T
Recessing tool
F
0.150 mm/rev
V
300 m/min
Machining
Groove position
Reference point
X0
60 abs
Z0
-70
B2
8 inc.
T1
4 inc.
α1
15 degrees
α2
15 degrees
FS1
1
R2
1
R3
1
FS4
1
D
2 inc.
U
0.100 inc.
N
1
 Press the
softkey
