Siemens SINUMERIK 840D sl Operation/Programming

11
Examples 08/2005
11.1 Standard machinin
g
p
rocesses
11
♥ Siemens AG, 2005. All rights reserved
11-416 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
G
0
S
400 rpm
Cut division
Diminishing
Machining type
Thread
Outside threads
X0
48 abs
Z0
0 abs
Z1
-25 abs
W
4 inc.
R
4 inc.
K
1.226 inc.
α
30 degrees
Infeed
AS
10
U
0.020 inc.
V
1 inc.
Q
0 degree
 Press the
softkey
12. Longitudinal threads
M48x2 (finishing)
 Press the
Thread Thread
long.
softkeys
 Enter parameters:
T
Threading tool_2
P
2 mm/rev
G
0
S
400 rpm
Machining type
Thread
Outside threads
X0
48 abs
Z0
0 abs
Z1
-25 abs
W
4 inc.
R
4 inc.
K
1.226 inc.
α
30 degrees
Infeed
V
1 inc.
Q
0 degree
 Press the
softkey
13. Drilling
 Press the
Drilling
Reaming >
Drilling
softkeys
 Enter parameters:
