Siemens SINUMERIK 840D sl Operation/Programming

11
08/2005 Examples
11.1 Standard machinin
g
p
rocesses
11
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 11-417
T
Drill
F
200 mm/min
S
1000 rpm
Position
Front
Point/Shaft
Tip
Z1
10 inc.
DT
0 s
 Press the
softkey
14. Position
 Press the
Positions
>
softkeys
 Enter parameters:
Position
Front
Right-angle/Polar
Polar
Z0
0 abs
C0
0 abs
L0
16 abs
C1
90 abs
L1
16 abs
C2
180 abs
L2
16 abs
C3
270 abs
L3
16 abs
 Press the
softkey
15. Mill a rectangular pocket
 Press the
Pocket
>
Rectang.
pocket
softkeys
 Enter parameters:
T
Milling tool
F
0.030 mm/tooth
S
1800 rpm
Position
Front
Machining type
Position
Single position
X0
0 abs
Y0
0 abs
Z0
0 abs
W
23
L
23
R
8
α0
4 degree
Z1
5 inc.
DXY
50 %
