Table 5-7 Plug&Measure installation of a PM into an existing (congured) device / replacement of
a PM in an existing (congured) device
Case Description Data synchronization/Action
PU AMx
New Un‐
change
d
The PM electronics is replaced. "-" is dis‐
played instead of the serial number. At
least one AM remains in the device.
Automatic data synchronization
1)
, no
action required by user.
When there are two AMs in the device,
the new PM always synchronizes with
AM1.
The PM receives the data of the previ‐
ously used PM, including its serial num‐
ber
2)
New Un‐
change
d
PM electronics with new serial number is
installed.
Automatic data synchronization
1)
, no
action required by user.
In this scenario, the replacement of the
PM electronics results in a loss of data of
the previously installed PM. In addition,
the serial number is overwritten.
1)
Data synchronization: PM parameters are transferred to the AMx (x=1 or 2), parameters of the AMx are
transferred to the PM
2)
Serial number stored in the PM is also the serial number of the device
Table 5-8 Plug&Measure-Replacement of a PM/Installation of a used AM
Case Description Data synchronization/Action
PM AMx
Re‐
placed
Re‐
placed
Assembly from inventory: Each module
has a serial number and has been con‐
nected to another module before. AM of
the same type is replaced.
User action. Conrm with <ENTER> or
reject with <ESC>.
When the process is conrmed, stored
AM data is transmitted to the replaced
AM.
Re‐
placed
Re‐
placed
Assembly from inventory: Each module
has a serial number and has been con‐
nected to another module before. AM of
a dierent type is replaced.
Automatic data synchronization
1)
, no
action required by user. Each module re‐
tains its data.
1)
Data synchronization: PM parameters are transferred to the AMx (x=1 or 2), parameters of the AMx are
transferred to the PM
Combined operation
5.5Plug & measure permitted activities
Wall-mounted device
56 Operating Instructions, 07/2023, A5E31930403-AB
