Siemens AG ⋅ January 1999
Table 2.1 Selection and order data
Order no.
Numerical line differential protection
7SD600
j - jj A00-j DA0
Nominal current; nominal frequency
20 mA; 50/60 Hz (without external summation transformer)
1 A 50/60 Hz; with external summation transformer 4AM4930-7DB
5 A 50/60 Hz; with external summation transformer 4AM4930-6DB
0
1
5
Nominal auxiliary supply voltage
24, 48 V-
60, 110, 125 V
220/250 V-/115 V, 50/60 Hz
2
4
5
Constructional details
in housing for panel surface mounting with terminals at the side
in housing for panel surface mounting with terminals at the top/bottom
in housing for panel flush mounting/cubicle mounting
B
D
E
Operating language
English - can be changed to German, Spanish 0
Functional scope
Differential protection
Differential protection, harmonic restraint
Differential protection, pilot wire monitoring, remote tripping
Differential protection, pilot wire monitoring, remote tripping, harmonic restraint
0
1
2
3
Accessories
D Copper connection cable
between PC (9-pin socket) and converter/protection device
D Converter RS232 - RS485
with 2.5 m connection cable, PC adapter with plug-in power supply unit 110/220 V-
D Converter full-duplex fiber optic cable - RS485
with 2.5 m connection cable, with auxiliary supply voltage 24 to 250 V- and 110/220
V
D Protection operating software DIGSI (stage 1)
Parameterization and operating software (German)
Min. requirements: MS WINDOWS V3.1, WINDOWS 95 or WINDOWS NT 4.0
D Graphic evaluation program DIGRA
for visualization of fault recording in connection with DIGSI (German);
Min. requirements: MS WINDOWS V3.1, WINDOWS 95 or WINDOWS NT 4.0 and
DIGSI
D Summation transformer 1 A, 50/60 Hz for 7SD600
D Summation transformer 5 A, 50/60 Hz for 7SD600
7XV5100-2
7XV5700-0AA00
7XV5650-0AA00
7XS5120--0AA0
7XS5130-0AA0
4AM4930-7DB
4AM4930-6DB
