Siemens AG ⋅ January 1999
A
B
6 3 M A R S H
L E D
"
Beginning of the blocks "Marshalling of the LEDs"
Use the " key to go to the first marshallable LED:
A
B
6 3 M A R S H
L E D 1
"
Marshalling for LED 1
Switch to the selection level with the "key:
A
6 3 L E D 1 1
L o c k O u t
B
LED 1 is factory set as follows:
1. Lockout state of the trip command, stored display;
Fno. 3031
A
6 3 L E D 1 2
not all.
Y
B
2. No further signal functions for LED 1
The "+" key lets you call up all marshallable output
functions on the display once you have entered the
code word. The "-" key also lets you scroll backĆ
wards through the list of alternatives. The required
function is confirmed with the enter key . Additional
functions under further index numbers (1 to 20) can
then be selected for LED 1 using the B key. Each
selection must be confirmed with the key. If the
slot of a physical module is not assigned, the "not
all." function (not allocated) is selected.
You can exit the selection level of LED 1 with the A
key. Scroll to the next LED with the B key.
Table 5.5 Factory set LEDs
4th operating level 5th operating level Fno. Comment
MARSHALLING LEDs Block heading
63 MARSH LED 1
6 3 L E D 1 1
L o c k O u t
3031 Lockout state of trip command
63 MARSH LED 2
6 3 L E D 2 1
Dev. Gen.Tr. M
511 Protection (gen.) General trip
63 MARSH LED 3
6 3 L E D 3 1
F a u l t W M
3376 Fault in the pilot wire monitoring
63 MARSH LED 4
6 3 L E D 4 1
B . D I F . S
B . D I F . M
B . D I F . H
3024
3030
3026
Blocking by saturation in the differential current
Blocking by DIFF current monitoring
Blocking by harmonics
