' $ ! $!& #$"&&"!  Ċ (%& !' $$ !" 
 
5 - 25
Siemens AG January 1999
Switch to the selection level with the "key:
A
6 2 S R 2 1
Fault P W
B

Signal relay 2 has the following factory setting:
Fault in the pilot wire connection (if pilot wire monitoĆ
ring available)
A
6 2 S R 2 2
not a l l.
Y
B

No further signal functions for signal relay 2
The "+" key lets you call up all marshallable output
functions on the display once you have entered the
code word. The "-" key also lets you scroll backĆ
wards through the list of alternatives. Confirm the
required function with the enter key . Additional
functions under further index numbers (1 to 20) can
then be selected for signal relay 1 using the B key.
Each selection must be confirmed with the E key. If
the slot of a physical module is not assigned, the
"not all." function (not allocated) is selected.
Exit the selection level of signal relay 1 with A. Scroll
to the next signal relay with the B key.
Table 5.3 Marshallable binary output functions
Fno. Short text
(display on LCD)
Logical function
1
5
52
501
511
1157
1174
1185
3003
3008
3015
3016
3017
3021
3022
3024
3026
3027
3028
3030
3031
3303
3306
3312
3316
3333
3341
3342
3343
not all.
> Res. LED
PF act
DEV.sta
DEV.Tr.
>CBcl
CB test
CB test Tr.
>DIFblk
>Res.LO
DIF.off
DIF.blk
DIF.act
PROL.st
DIF.Tr
B.DIF S
B.DIF H
DIF.PR.Tr.
TT.sen
B.DIF M
Lockout
>REM blk
>REM Tr.
REM blk.
RT send
>Rem.Tr.bl
REM.off
OFF.blk
REM.off.act
Not allocated
>Reset LEDs
At least one protective function is active
General starting
Protection (gen.) general trip
>CB auxiliary contact all poles closed
Circuit-breaker test in progress
CB test trip 3-phase
>Blocking of DIF protective function
>Reset Lockout function
Differential protection is switched off
Differential protection blocked
Differential protection active
Prolongation for trip IDIFF> started
Diff protection general trip
Blocking due to saturation in DIFF current
Blocking due to harmonics
Diff protection tripping stage IDIFF>
Transmitting transfer trip signal
Blocking by DIFF current monitoring
Lockout state of trip command
>Blocking of inter trip
>Inter trip of remote station
Inter trip is blocked
Transmitting inter trip signal
>Blocking of trip by remote station
Trip from remote station is switched off
Trip from remote station blocked
Trip from remote station active
