Mounting and Commissioning
3.2 Checking Connections
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
307
USB Interface
The USB interface can be used to establish a connection between the protection device and your PC. For the
communication, the Microsoft Windows USB driver is used which is installed together with DIGSI (as of version
V4.82). The interface is installed as a virtual serial COM port. We recommend the use of standard USB cables
with a maximum length of 5 m/16 ft.
Table 3-2 Assignment of the USB socket
Connections at port A
If the interface is used for communication with the device, the data connection is to be checked.
When using the port as input for one or two RTD boxes, you should check the interconnection according to one
of the connection examples A.3.
Table 3-3 Assignment of the port A socket
Pin No. 1 2 3 4 Housing
USB VBUS (unused) D- D+ GND Shield
Pin No. Ethernet interface
1Tx+
2Tx-
3Rx+
4—
5—
6Rx-
7—
8—
