Appendix
A.9 Information List
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
455
235.2125 Function $00 TRIP Delay Time
Out ($00 Time Out)
Flx OUT On
Off
On
Off
**LED BO
235.2126 Function $00 TRIP ($00 TRIP) Flx OUT On
Off
on * * LED BO
235.2128 Function $00 has invalid settings
($00 inval.set)
Flx OUT On
Off
On
Off
**LED BO
236.2127 BLOCK Flexible Function (BLK.
Flex.Fct.)
Device, General IntSP On
Off
* * * LED BO
253 Failure VT circuit: broken wire
(VT brk. wire)
Measurem.Superv OUT On
Off
**LEDBO
255 Failure VT circuit (Fail VT circuit) Measurem.Superv OUT On
Off
**LEDBO
256 Failure VT circuit: 1 pole broken
wire (VT b.w. 1 pole)
Measurem.Superv OUT On
Off
**LEDBO
257 Failure VT circuit: 2 pole broken
wire (VT b.w. 2 pole)
Measurem.Superv OUT On
Off
**LEDBO
258 Failure VT circuit: 3 pole broken
wire (VT b.w. 3 pole)
Measurem.Superv OUT On
Off
**LEDBO
264 Failure: RTD-Box 1 (Fail: RTD-
Box 1)
RTD-Box OUT On
Off
**LEDBO
267 Failure: RTD-Box 2 (Fail: RTD-
Box 2)
RTD-Box OUT On
Off
**LEDBO
272 Set Point Operating Hours (SP.
Op Hours>)
SetPoint(Stat) OUT On
Off
* * LED BO 135 229 1 Yes
301 Power System fault
(Pow.Sys.Flt.)
Device, General OUT On
Off
On
Off
135 231 2 Yes
302 Fault Event (Fault Event) Device, General OUT * on 135 232 2 Yes
303 sensitive Ground fault (sens Gnd
flt)
Device, General OUT On
Off
320 Warn: Limit of Memory Data ex-
ceeded (Warn Mem. Data)
Device, General OUT On
Off
**LEDBO
321 Warn: Limit of Memory Parameter
exceeded (Warn Mem. Para.)
Device, General OUT On
Off
**LEDBO
322 Warn: Limit of Memory Operation
exceeded (Warn Mem. Oper.)
Device, General OUT On
Off
**LEDBO
323 Warn: Limit of Memory New ex-
ceeded (Warn Mem. New)
Device, General OUT On
Off
**LEDBO
356 >Manual close signal (>Manual
Close)
P.System Data 2 SP * * * LED BI BO 150 6 1 Yes
395 >I MIN/MAX Buffer Reset (>I
MinMax Reset)
Min/Max meter SP on * * LED BI BO
396 >I1 MIN/MAX Buffer Reset (>I1
MiMaReset)
Min/Max meter SP on * * LED BI BO
397 >V MIN/MAX Buffer Reset (>V
MiMaReset)
Min/Max meter SP on * * LED BI BO
398 >Vphph MIN/MAX Buffer Reset
(>VphphMiMaRes)
Min/Max meter SP on * * LED BI BO
399 >V1 MIN/MAX Buffer Reset (>V1
MiMa Reset)
Min/Max meter SP on * * LED BI BO
400 >P MIN/MAX Buffer Reset (>P
MiMa Reset)
Min/Max meter SP on * * LED BI BO
401 >S MIN/MAX Buffer Reset (>S
MiMa Reset)
Min/Max meter SP on * * LED BI BO
402 >Q MIN/MAX Buffer Reset (>Q
MiMa Reset)
Min/Max meter SP on * * LED BI BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
